iFrogLab F-60 Ble Bluetooth Transceiver Module, Low Power For App

iFrogLab F-60 Ble Bluetooth Transceiver Module, Low Power For App

Overview

  • Frequency Range: 2402~2480MHz
  • UART Data Interface
  • Sensitivity: -93dBm
  • Output Power: ≥3dBm
  • AES-128 Encryption and Decryption
  • Self-adaptable frequency hopping
  • Different power-saving modes
  • Four types of pairing mechnism
  • Supply voltage: 3.0~5.0V

Where can buy

ifrogLab official online shopping web site   , Amazon.com , ebay.com

Description

The Bluetooth 4.0 BLE for Arduino,Raspberry Pi , STM32 (Master/Slave and iBeacon) integrates an  Serial Bluetooth BLE module. It can be easily used with Arduino, Raspberry Pi for transparent wireless serial communication. You can choose two pins from Arduino D0 to D7 as Software Serial Ports to communicate with Bluetooth Shield (D0 and D1 is Hardware Serial Port). Support Central and Peripheral mode switch, modify by AT command. Support Remote control mode, remote device can control PIO pin or modify settings by AT commander when Connected. (such as Iphone4s/5/6 ipad, Note2 etc.) The Bluetooth UART serial Converter Module can easily transfer the UART data through the wireless Bluetooth, without complex PCB layout or deep knowledge in the Bluetooth software stack, you can combine this bluetooth module with your system: MCU, ARM or DSP systems. SOC systems. Personal Digital Assistants (PDAs) Computer Accessories Other systems your want to use under bluetooth functions. Device Features nordic 51822 Bluetooth Chip Solution Fully Qualified Bluetooth V4.0 Ble Full Speed Bluetooth Operation with Full Piconet Support and Scatternet Support Increadible samll size with 3.3V input, and RoHS Compliant UART interface and with baudrate setup function iBeacon Size: 28*13*2.3mm,

Video Demo and Training

we provide a lot of video for demo and training, all of code are open source sample code,

Open Source

for the open source sample code, please download from

https://github.com/iFrogLab/iFrogLab_F-60_UART

Screen Shot 2016-03-14 at 12.11.58 PM

Screen Shot 2016-03-14 at 12.13.50 PM Screen Shot 2016-03-14 at 12.12.48 PM  Screen Shot 2016-03-14 at 12.11.39 PM Screen Shot 2016-03-14 at 12.10.48 PM Screen Shot 2016-03-14 at 12.10.30 PM Screen Shot 2016-03-14 at 12.09.16 PM Screen Shot 2016-03-14 at 12.09.09 PM Screen Shot 2016-03-14 at 12.09.02 PM Screen Shot 2016-03-14 at 12.08.52 PM
